Intel Graphics Media Accelerator (GMA) 4500MHD
El Acelerador de Media Gráfica de Intel 4500MHD (algunas veces también llamado GMA X4500 HD o otras combinaciones) es un adaptador gráfico integrado que soporta DirectX 10 en el chipset GM45 de la plataforma Centrino 2 (Montevina). El chip no posee memoria de video dedicada, pero toma dinámicamente una cantidad de memoria principal (hasta 384 MB).
Comparado con el predecesor GMA X3100, el GMA 4500MHD tiene dos shaders más y una frecuencia de 33 MHz más alta. Por lo tanto, el chip es notablemente más veloz que el antiguo (especialmente en 3DMark06). Aun así, el rendimiento está en el nivel de tarjetas de video dedicadas de nivel de entrada e, por lo tanto no es adecuado para juegos exigentes.
Una nueva característica del chip GMA, son las nuevas funciones de decodificación de video HD. El GM45 es capaz de decodificar videos HD en los formatos AVC, VC-2, y MPEG-2 para ayudar al CPU. De esta forma una reproducción de Blu-Ray debe ser posible con un CPU de baja capacidad.
| Fabricante | Intel |
| Serie | GMA |
| Nombre Código | Montevina |
| Pipelines | 10 - unificado |
| Velocidad del núcleo * | 533 MHz |
| Shader Speed * | 533 MHz |
| Velocidad de Memoria * | |
| Ancho de Bus de Memoria | 0 Bit |
| Tipo de Memoria | mit Hauptspeicher geteilt (shared) bis 384 MB |
| Max. Cantidad de Memoria | 0 MB |
| Memoria Compartida | si shared Memory |
| DirectX | DirectX 10, Shader 4.0 |
| technology | 65 nm |
| Características | Tecnología Clear Video mejorada de Intel, Decodificador de Video HD (VC/VC2/MPEG2), HDMI con soporte para HDCP, Tecnología Display Refresh Rate Switching, Render Standby |
| Tamaño de la portátil | Pequeño y liviano |
| Fecha de Anuncio | 01.10.2008 |
| Link a la Página del Fabricante | http://www.intel.com/products/Centrino/c... |
Benchmarks
3DMark 2001: - Standard 1024x768
0%
100%
min: 4780, avg: 5877, max: 6557 Points ... More Details
3DMark 03: - Standard 1024x768
0% 100%
min: 1811, avg: 2367, max: 2630 Points ... More Details
3DMark 05: - Standard 1024x768
0% 100%
min: 1311, avg: 1428, max: 1515 Points ... More Details
3DMark 06:
0% 100%
min: 679, avg: 1036, max: 1896 Points ... More Details
Quake 3 Arena - Timedemo: - highest 1024x768
0% 100%
min: 75.4, avg: 102, max: 128.2 fps ... More Details
F.E.A.R.: - GPU min, CPU min 640x480
0% 100%
min: 69, avg: 76, max: 88 fps ... More Details
F.E.A.R.: - GPU medium, CPU medium 800x600
0% 100%
min: 14, avg: 18, max: 20 fps ... More Details
F.E.A.R.: - GPU: max, CPU: max 1024x768
0% 100%
min: 5, avg: 6, max: 6 fps ... More Details
Doom 3: - Low 640x480
0% 100%
min: 16.1, avg: 17, max: 17.2 fps ... More Details
Doom 3: - Medium 800x600
0% 100%
min: 17, avg: 17, max: 17 fps ... More Details
Doom 3: - High 800x600
0% 100%
min: 15.7, avg: 16, max: 15.7 fps ... More Details
Doom 3: - Ultra 1024x768
0% 100%
min: 13.2, avg: 13, max: 13.2 fps ... More Details
- Range of benchmark values for this graphics card - Average benchmark values for this graphics cardBased on 38 Benchmarks
| 3DMark 05in comparison | ||
| Intel Graphics Media Accelerator (GMA) 900 (min) | 234 | |
| ... | ||
| ATI Radeon Xpress X1250 | 1073 | |
| ATI Mobility Radeon 9700 | 1200 | |
| ATI Mobility FireGL V3200 | 1250 | |
| Intel Graphics Media Accelerator (GMA) 4500MHD | 1428 | |
| NVIDIA GeForce Go 7300 | 1448 | |
| NVIDIA GeForce Go 7200 | 1450 | |
| NVIDIA Quadro NVS 110M | 1500 | |
| ... | ||
| ATI Mobility Radeon HD 3870 X2 (max) | 20115 | |
